Fluorescent Pendant Light
JCY Series Fluorescent Pendant Light
The scope of application:
1. Applied to illumination of water dripping, water spattering, water coagulating place in ships, such as oven cabin, dry cabin, tunnel, pipeline and weather deck etc.
2. Working temperature: -20℃+55℃.
Product Feature:
1. The shell is made of high quality steel plate and the lampshade is made of high strength PC with excellent sealing performance.
2. To prevent from electric shocking, the lamp shell equipped with a cooper terminal is maked with .
3. Pin cap lampholder, wiring terminal inside, convenient to connect.
4. The lamp has B15d lampholder, used for 24v/15w emergency bulb, the edge of lampshade is maked with , please clarify if emergency device is needed when order.
5. Equipped compensating capacitance inside the lamp, with perfect turn on performance.
Standard: Conform to JIS8008-2002 standard and 《RULES FOR CLASSIFICATION OF SEA-GOING STEEL SHIPS》.
Specification：
|
Type
|
Power
|
Voltage
|
Compensating capacitance
|
Power factor
|
Lamp holder
|
Cable O.D.
|
Protection Class
|
Weight
|
|
JCY27-1
|
1X20W
|
110V/60HZ 220V/50HZ
220V/60HZ
|
4.75μf
|
>0.85
|
G13
|
Φ12-16
|
IP56
|
7.5kg
|
|
JCY27-2
|
2X20W
|
7.5μf
|
||||||
|
JCY27-1B
|
2X20W
24V/15W
|
7.5μf
|
||||||
|
JCY27-2B
|
7.5μf
|
